RCD Tester / RDC Meter / KYORITSU MODEL 5406A

RCD Tester / RDC Meter / KYORITSU MODEL 5406A RCD Tester / RDC Meter / KYORITSU MODEL 5406A • Custom microprocessor controlled for highest accuracy and reliability. • 3 LEDs for checking correct wiring status. • 0 and 180 degree phase angle switch permits quick tests and consistent readings. • Digital read-out of tripping time. • Constant current source circuitry ensures that a fluctuating mains voltage does not affect the accuracy of readings. • Large custom digital display readout. • Visual indication of reversed phase and neutral wiring at socket. • Designed to IP54 Rating. • Complies with IEC 61557 • Test of a large kind of RCD' s: Standard, Selective, AC and A ( DC sensitive breakers) Rated Tripping Current | 10/ 20/ 30/ 200/ 300/ 500mA Fault Condition Settings | × 1/ 2, × 1, × 5, × DC, | AUTO RAMP Trip Current Duration | 1000ms, 200ms ( × 5) Lowest Resolution | 1ms Trip Time Accuracy | ± 0.6% rdg± 4dgt Operating Voltage | 230V+ 10% -15% | ( 195V~ 253V) 50Hz Safety Standard | IEC 61557-1, -6 | IEC 61010-1 CAT.III 300V | IEC 61010-2-031 Pollution Degree 2 Withstand Voltage | 3700V AC for 1 minute IP Rating | IEC 60529-IP54 Dimensions | 186( L) × 167( W) × 89( D) mm Weight | 800g approx. Accessories | Molded plug test leads | Pouch for test leads | Shoulder Strap | Instruction Manual Optional | 7121B ( Simplified measurement probe)
